Diamond SERIES

7245ZA
Battery Pack

Review the catalogue data, then discuss your installation and operating requirements.

Imported from existing project records, not independently reverified in this prototype. Product imagery is not evidence of compatibility or performance.

DISCUSS THIS MODEL

Catalogue specifications

Module model	12.8V40Ah
Nominal voltage	76.8V
Rated capacity	40Ah
Rated energy	3072Wh
Charge voltage limit	87.6V
Discharge cutoff voltage	60V
Maximum charge current	20A
Maximum discharge current	50A
Discharge temperature	-20℃~60℃
Charge temperature	-10℃~55℃
Compatible motor power	≤1500W
Weight	21±1kg
Communication	Bluetooth
Ingress protection	IPX7

Source record: p02-03 · Existing product catalogue dated 2026-05-09. Check the original manual and drawing before purchase.

Before selecting this pack

Confirm system voltage, charger settings, continuous and peak current, enclosure dimensions, connector orientation, communication and mounting. No universal vehicle compatibility is implied.
